China popualar plywood,acrylic, plastic, glass/ wood craft laser engraving cutting machine 1325 1530 2030 2040

  • Product Item: INJ2040L
  • Category: Co2 laser engraver
  • 2040 laser machine
  • plywood laser cutting machine
  • wood laser cutting machine
  • laesr 2040
  • Product Manual:China popualar plywood,acrylic, plastic, glass/ wood craft laser engraving cutting machine 1325 1530 2030 2040
  • SPECIFICATION

    China popular plywood,acrylic, plastic, glass/ wood craft laser engraving cutting machine 1325 1530 2030 2040



    Technology parameter

    Item  /  Model

    RDJ-1390

    Cutting area

    1300 x 900mm

    Laser power

    80W/100w/150w/180w

    Laser type

    CO2 sealed laser tube,water-cooled,10.6um

    Engraving speed

    0-60000mm/min

    Cutting speed

    0-40000mm/min

    Laser Output

    1-100%software setting

    Resetting positioning accuracy

    ≤±0.01mm

    Power supply

    220V/50HZ (Optional 110V/60HZ)

    Operating temperature

    0 - 45°C

    Operating humidity

    5 - 95%

    Min. shaping character

    English 1.0 x 1.0mm

    Graphic format supported

    BMP, PLT, DST, DXF, AI

    Software supported

    TAJIMA, CorelDraw, Photoshop, AutoCAD

    Driving system

    stepper motor

    Cooling mode

    Water-cooling and protection system

    Equipment Dimensions

    1990x1400x1470mm

    Net Weight:

    1550kg

    Shipping Dimensions

    2090 x 1500 x 1570mm

    Optional Spare Parts

    Up-down clump, Rotary System, Honeycomb table

    Recommended Spare Parts

    Laser Tube and Lens


    Machine parts of 2040 laser



    >> Laser cutting machine features:

    1. 3mm Cold-rolled steel welded machine bed, strong and running stable.

    2. Aluminium blade table: to process hard materials like acrylic, wood and so on.

    3. Fireproof window,more security.

    4.CO2 Glass sealed laser tube China famous brand (EFR, Reci), good beam mode stability, service time over 8500~10000 working hours.

    5. Laser Power 40W~180W, good quality and stable output to prolong the laser tube service time.

    6. Singapore imported lens and mirrors. High transmittance, good focusing, reflecting effect.

    7. Ruida or Leetro Controller USB interface, support online/offline working, English language system, adjustable cutting speed and power.

    8. High accuracy stepper motors and drivers. Belt transmission.

    -->
